Powder Packing Machine Detergent Powder Chilli Powder Masala Powder
Mini Doypack Pouch
Machine Specification:
| Item | 200 | 300 | 430 |
| Bag Material | Multilayer Composite Premade Bag (e.g.: PET/PE) |
| Bag size | 100mm≤L≤200mm | 100mm≤L≤300mm | 100mm≤L≤430mm |
| 70mm≤W≤150mm | 80mm≤W≤300mm | 80mm≤W≤300mm |
| Bag Type | 3 Side Seal Bag, Stand-up Bag |
| Upgradable Bag Type | N/A | Gusset Bag, Zipper Bag, Flat Bottom Pouch
(Need additional purchase of functional device) |
| Speed | 0~26bags/min | 0~15bags/min |
| Sealing Type | Plain weave | Straight grain, pitch is 1mm (Optional reticulate) |
| Sealing Width | 8mm | 10mm(5--20mm can be customized) |
| Voltage | 220V, Single-phase, 50/60HZ, 1KW | 220V, Single-phase, 50/60HZ, 1.2KW |
| Air Pressure | 0.65Mpa |
| Air Consumption | 0.2m³/min | 0.3m³/min |
| Standard machine, no additional function |
| Body Dimension | 1080*535*1010mm | 1770*600*1230mm | 1770*600*1360mm |
| Packing Dimension | 1240*670*1320mm | 1860*710*1550mm | 1860*710*1650mm |
| Export non-fumigation wooden case |
(We can provide you with exclusive customized services according to
your needs!)
In this era of mechanization and intelligent development, machine
equipment gradually replaces manual operation, with small error
probability, high speed and stable operation, which accelerates the
rapid flow of finished products into the market, and our packaging
machine can easily switch from granules to powder packaging. In the
process, you only need to change the suitable weighing machine.
The Mini Doypack packing machine is specially developed for the
packaging application of various composite film prefabricated bags,
with compact structure and reasonable action. It adopts the
touch-type color touch screen interface operation, the upper bag is
placed, the orientation is adjustable, and a single machine can
operate a variety of bag types and sizes, and the switching is
simple and the workload is small.
Mini Doypack packing machine is controlled by microcomputer central
processing unit (PLC), triggered by solenoid valve, driven by air
cylinder, and operated by sensor on-line to monitor the operation.
Soft suction cups are used to complete the main effective actions
such as pouch taking, conveying, and bag opening, and emergency
stop and vacuum are set. The sensor function ensures stable, smooth
and safe operation.
The Mini Doypack packing machine can be operated with various types
of feeding and weighing equipment, and can be used for different
material packaging requirements, such as granular materials,
powders, sauce liquids and other food and non-food products. The
weighing equipment is controlled by the host PLC, and the
connection is simple. The action mode and unloading time of the
host can be adjusted according to different material properties and
packaging volumes to achieve the best packaging effect.
